Press .
The MOD Output BNC will output the 1kHz sine wave.
In addition, you can use and the Rotate Knob to modify the
value you need.
6.13 Setup of Trigger
The Trigger function offers internal trigger source signals. Besides, You can
select the signal from external (From Modulation/Trigger Input BNC).
Set the main output function by pressing button .
Set the main output Amplitude by pressing button and number keys.
Set the main output frequency by pressing button and number keys.
Select the Trigger type by pressing button.
Select the Trigger signal source by pressing button.
Press to set up Trigger signal RATE value (Range 0.01Hz ~ 10kHz).
Press to set the Duty of Internal trigger signal (Range
90%:10%:90%).
Select the Trigger start Phase by pressing button and number keys.
GFG-3015 offers -90º ~ +80º range for internal trigger mode.
Press to start performing Trigger function.
