4. PANEL CONTROLS AND INDICATORS
4
- 1 Front panel
@ CV indicator
@ CC indicator
@ Voltage coarse
@ Voltage fine
) Current coarse
@ Current fine
"+" output terminal
\l.,
@ " GND terminal
@ "-" output terminal
@ meter
3 meter
@ AN selects switch
Power control
@ Current HIILO control
lights when the power turn on and constant voltage operation.
lights when this unit in constant current operation.
for the coarse adjustment of the output voltage.
for the fine adjustment of the output voltage.
for the coarse adjustment of the output current.
for the fine adjustment of the output current.
positive polarity (Red).
earth and chassis ground (Green).
negative polarity (Black).
indicates the output voltage (Analog type).
indicates the output voltage or current (Digital type).
indicates the output current (Analog type).
selects the meter indicates of the output voltage or current (Digital type).
onloff switch.
current indicates
HI/LO range SELECTS.
4 - 2 Rear panel
Fuse holder
@ Power cord
AC selects switch With
switch selects the line voltage at the high end (Right position) of the range
120V or 240V and at the low end (left position) of the range
100V or 220V.
@ AC selects switch
Selects the line Voltage is in the
100V-120V range (left position) or is in the 220V-240V range
(Right position).
@ Master - Slave Switch
Selects for Master (internal control) or Slave (external remote control) tracking operation.
@ Input - Output connector
With
@ Master-Slave switch selects, permit from the Master unit (SER. or PAR.) output
connected to Slave unit
(SER. or PAR.) inputs.
