GW Instek GPT-9803 User Manual

GPT-9000/9000A Series User Manual
172
Windows Comparator Method
Yes
TIMER (Test Time)
0.5S~999.9S
GND
OFF
Interface
REMOTE (Remote terminal)
Yes
SIGNAL IO
Yes
RS232
Yes
USB (Device)
Yes
GPIB
Yes (OPTION)
General
DISPLAY
240 x 64 dot matrix LED back light LCD
MEMORY
AUTO/MANU mode 100 memory blocks total
POWER SOURCE
AC100V/120V/220V/230V 10%
50Hz/60Hz
ACCESSORIES
Power cord x1, Quick Start Guide x1
User Manual x1 (CD)
GHT-114x1 for GPT-9801/9802/9803/9901A/
9902A/9903/9903A
GHT-114x1, GTL-115x1 for GTP-9804/9904
DIMENSIONS & WEIGHT
GPT-98XX: Approx. 330(W) x 148(H) x 452(D) mm
(Max.), 19kg(Max)
GPT-99XX: Approx. 330(W) x 148(H) x 587(D) mm
(Max.), 27kg(Max)
GPT-99XXA: Approx. 330(W) x 148(H)
x 482(D) mm(Max), 24kg(Max)
Table 1a: Output Limitation in Withstanding Voltage Testing (GPT-98XX)
Upper Current
Pause
Output Time
AC
30mA≤I≤40mA
At least as long
as the output
time
Maximum 240
seconds
0.001mA≤I<30
mA
Not necessary
Continuous
output possible
DC
0.001mA≤I≤10
mA
Not necessary
Continuous
output possible
GB
15A<I≤30A
At least as long
as the output
time
999.9
3A≤I≤15A
Not necessary
999.9
NOTE: Output Time = Ramp Time + Test Time.
