GW Instek GPT-9902A - GPT-9904 Dimensions

APPENDIX
177
GPT-9904 Dimensions
322.0
134.0
147.7
530.9
593.7
Tester
AC / DC Withstanding Voltage /
Insulation Resistance / Ground Bond
GPT-9904
PASS FAIL TESTREADY
CAUTION
HIGH VOLTAGE
5.0 kVAC MAX.
6.0 kVDC MAX.
HI-POT
IR
RETURN
SENSE L
SOURCE L
GB Rx
SENSE H
SOURCE H
UTILITYEDIT/SAVEMANU/AUTO
REMOTE
STOPSTART
POWER
ESC PAGE
