LCR-800 Series User Manual
1
1. INTRODUCTION
The precise LCR meter series are automatic, user programmable instruments
that provide high reliability and great precision for measuring a wide variety of
impedance parameters. The frequency range of LCR-819/829 covers from 12Hz
to 100kHz, LCR-817/827 from 12Hz to 10kHz, and LCR-816/826 from 100Hz
to 2kHz. The basic accuracy is 0.1% for LCR827/829, 0.05% for LCR-817/819,
and 0.2% for LCR-816/826. The measured results can be displayed on the high
quality LCD monitor with decimal points and units. The measured result
resolution is five full digits for Inductance (
L), Capacitance (C), and Resistance
(
R) (four full digits for Dissipation (D), Quality factor (Q) or C with R). In the
meantime, the LCD monitor is also shown the control status and parameters of
settings. The keypads are easy for menu programming. The LCR Meters’ test
fixture (option) is a method of convenient, reliable, guarded 4-terminal/2 wires
connection of radial and axial leaded components to the LCR Meters. Test
conditions can be stored and recalled from internal memory that will reduce the
setup time for measurement preparing.
