H3C S5120V2-LI

49
S5120V2-10P-SI & S5120V2-10P-LI
Figure 64 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP port LED
(4) System status LED (SYS)
(5) Console port (CONSOLE)
(6) SFP port
Figure 65 Rear panel
(1) Grounding screw
(2) AC-input power receptacle
S5120V2-20P-LI
Figure 66 Front panel
(1) 10/100/1000BASE-T autosensing Ethernet port
(2) 10/100/1000BASE-T autosensing Ethernet port LED
(3) SFP port LED
(4) System status LED (SYS)
(5) Console port (CONSOLE)
(6) SFP port
1 3
2
56
4
21
1
2 3
46 5
