H3C S5500-28 C-EI-DC

1-20
Figure 1-15 Front panel of short-haul dual-port 10 GE CX4 interface module
A short-haul dual-port 10 GE CX4 interface module provides two 10 Gbps electrical ports and supports
CX4 electrical and protocol standards. Only H3C’s CX4 power cables can be used for connecting the
CX4 ports. A CX4 cable is hot swappable and its maximum transmission distance is 3 m (9.84 ft.), which
is suitable for short-distance connections only.
Table 1-18 CX4 cables supported by the short-haul dual-port 10 GE CX4 interface module
CX4 Cable Connector type Length
LSPM2STKA 0.5 m (19.69 in.)
LSPM2STKB 1 m (39.37 in.)
LSPM2STKC
4X Infiniband
3 m (118.11 in.)
Figure 1-16 CX4 cable
Dual-Port 10 GE SFP+ Interface Module
Figure 1-17 Dual-port 10 GE SFP+ interface module
