5-7
Step2 Select Transfer > Send File in the HyperTerminal’s window. Click Browse in the pop-up dialog box (as
shown in
Figure 5-5) to select the application file to be downloaded (for example, bootrom.btm), and
select Xmodem from the Protocol drop-down list.
Figure 5-5 Send file dialog box
Step3 Click Send. The following dialog box appears:
Figure 5-6 Page for file sending
After the Boot ROM file is downloaded, the terminal displays the following information:
CCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCCdone!
Bootrom updating..........done!
Your baudrate should be set to 9600 bps again!
Press enter key when ready
You do not need to reset the HyperTerminal’s baud rate and can skip the last step if you have chosen
9600 bps. In this case, the system returns to the Boot ROM update menu directly instead of displaying
the prompt "Your baudrate should be set to 9600 bps again! Press enter key when ready".
