H3C S6850-56HF User Manual

1-9
Item S9850-4C S9850-32H
Fan tray slots 2 5
Power module slots 4 2
Expansion slots 4 N/A
Power module specifications
Power input AC input, DC input, high-voltage DC input
Power
specifications
See "Power modules"
Power consumption
Typical power
consumption
(Fully configured
with copper cables,
at 50% load)
• With four LSWM18CQ modules:
355 W
• With four LSWM18CQMSEC
modules: 443 W
• With four LSWM116Q modules: 311
W
• With four LSWM18QC modules:
251 W
• With four LSWM124XG2Q
modules: 363 W
• With four LSWM124XGT2Q
modules: 487 W
• With four LSWM124XG2QFC
modules: 363 W
• With four LSWM124XG2QL
modules: 275 W
• With four LSWM124TG2H modules:
355 W
• With four LSWM116FC modules:
311 W
• Single AC input: 198 W
• Dual AC inputs: 210 W
• Single DC input: 197 W
• Dual DC inputs: 208 W
Maximum power
consumption
(Fully configured
with transceiver
modules, at 100%
load)
• With four LSWM18CQ modules:
688 W
• With four LSWM18CQMSEC
modules: 748 W
• With four LSWM116Q modules: 616
W
• With four LSWM18QC modules:
496 W
• With four LSWM124XG2Q
modules: 616 W
• With four LSWM124XGT2Q
modules: 868 W
• With four LSWM124XG2QFC
modules: 616 W
• With four LSWM124XG2QL
modules: 520 W
• With four LSWM124TG2H modules:
688 W
• With four LSWM116FC modules:
616 W
• Single AC input: 376 W
• Dual AC inputs: 385 W
• Single DC input: 373 W
• Dual DC inputs: 377 W
Thermal consumption
Typical thermal
consumption
• With four LSWM18CQ modules:
1211 BTU/hr
• Single AC input: 676 BTU/hr
• Dual AC inputs: 717 BTU/hr
