H3C S6850-56HF

3-33
LSWM18CQMSEC
The LSWM18CQMSEC interface module provides eight QSFP28 ports that all support MACsec.
Figure3-11 LSWM18CQMSEC front panel
(1) QSFP28 port LED
(2) QSFP28 port
Ports and LEDs
For information about the ports and modules and cables available for the ports, see "QSFP28 port."
For information about the LEDs, see "QSFP28 port LED."
Technical specifications
Table3-15 Technical specifications
Item Specifications
Dimensions (H × W × D)
40.1 × 214 × 274 mm (1.58 × 8.43 × 10.79 in), including the connector but
excluding the ejector lever
Weight 2 kg (4.41 lb)
Power consumption (static) 48 W
Power consumption (typical) 70 W
Power consumption (fully
loaded)
93 W
LSWM116Q
The LSWM116Q interface module provides 16 QSFP+ ports.
Figure3-12 LSWM116Q front panel
(1) QSFP+ port LED
(2) QSFP+ port
Ports and LEDs
For information about the ports and modules and cables available for the ports, see "QSFP+ port."
For information about the LEDs, see "QSFP+ port LED."
