26
Tunnel source 1.1.1.1
Tunnel keepalive enabled, Period(20 s), Retries(2)
Network ID 1
Tunnel protocol/transport GRE_EVI/IP
Output queue - Urgent queuing: Size/Length/Discards 0/100/0
Output queue - Protocol queuing: Size/Length/Discards 0/500/0
Output queue - FIFO queuing: Size/Length/Discards 0/75/0
Last clearing of counters: Never
Last 300 seconds input rate: 0 bytes/sec, 0 bits/sec, 0 packets/sec
Last 300 seconds output rate: 0 bytes/sec, 0 bits/sec, 0 packets/sec
Input: 0 packets, 0 bytes, 0 drops
Output: 0 packets, 0 bytes, 0 drops
# Display information about EVI links.
[SwitchA] display evi link interface tunnel 1
Interface Status Source Destination
EVI-Link0 UP 1.1.1.1 1.1.2.1
EVI-Link1 UP 1.1.1.1 1.1.3.1
# Display ENDS information.
[SwitchA] display evi neighbor-discovery server summary
Interface Local Address Network ID Auth Members Vpn-instance
Tunnel1 1.1.1.1 1 disabled 3 [No Vrf]
# Display ENDC information.
[SwitchA] display evi neighbor-discovery client summary
Status: I-Init E-Establish P-Probe
Interface Local Address Server Address Network ID Reg Auth Status Vpn-instance
Tunnel1 1.1.1.1 1.1.1.1 1 15 disabled E [No Vrf]
# Display EVI neighbors registered with the ENDS.
[SwitchA] display evi neighbor-discovery server member
Interface: Tunnel1 Network ID: 1 Vpn-instance: [No Vrf]
IP Address: 1.1.1.1
Client Address System ID Expire Created Time
1.1.1.1 000F-0001-0001 25 2013/01/01 00:00:43
1.1.2.1 000F-0001-0002 15 2013/01/01 01:00:46
1.1.3.1 000F-0001-0003 20 2013/01/01 01:02:13
# Display neighbor entries that Switch A has learned.
[SwitchA] display evi neighbor-discovery client member
Interface: Tunnel1 Network ID: 1 Vpn-instance: [No Vrf]
Local Address: 1.1.1.1
Server Address: 1.1.1.1
Neighbor System ID Created Time Expire Status
1.1.2.1 000F-0001-0002 2013/01/01 12:12:12 13 Up
1.1.3.1 000F-0001-0003 2013/01/01 12:12:12 12 Up
# Verify that MAC addresses in VLAN 100 have been filtered by the routing policy on Switch A.
[SwitchA] display evi isis local-mac dynamic
Process ID: 0
Tunnel interface: Tunnel1
VLAN ID: 100
MAC address: 0001-0100-0001 (Filtered)
