8
Figure 8 Controller Configuration screen
4. On the screen as shown in Figure 9, select a storage controller operating mode, and press
Enter.
Table 3 describes the storage controller operating modes.
Figure 9 Selecting a storage controller operating mode
Table 3 Storage controller operating modes
RAID: expose RAW
All RAID functions can be used. Raw physical drives are exposed to the
system.
RAID: hide RAW
All RAID functions can be used. Raw physical drives are not exposed to the
