5
Figure 2 Models of the WA2600 enhanced series
Table 1 Physical dimensions and weight of the WA2600 enhanced series
Physical dimensions
(H×W×D)
35 × 210 × 150 mm (1.38 ×
8.27 × 5.91 in.)
35 × 210 × 150 mm (1.38 ×
8.27 × 5.91 in.)
Hardware configuration
The two models of the WA2600 enhanced series have different radio frequencies (RFs)
and structures. For supported protocols and chassis material, see Table 2
Table 2 Supported protocols and chassis material
Protocols and chassis material
IEEE 802.11a/b/g/n, single-RF, sheet metal
IEEE 802.11a/b/g/n, dual-RF, sheet metal
Leds
The LEDs on the panel vary by model. For details about the LEDs, see Figure 3 Figure 4
and Table 3
