Important components
1. Push handle
2. Waste bin
3. Waste bin handle
4. Disc brush height adjustment
5. Carrying handle
6. Disc brush
7. Side guide roller (not 475)
8. Running wheel
9. Fine dirt sweeping roller
10. Holding-down device (not 475)
11. Dust filter (not 475)
12. Machine number (477/497)
13. Machine number (475)
14. Angled wheel
15. Sweeping lip
16. Sweeping plate
17. Clutch
18. Toothed sleeve
19. Gear protection (not 475)
2
3
4
5
6
7
8
10
1
13
3 Design and function
11
15
14
16
9
6
18
19
14
17
9
12
13
