96-8000 411
OPTIONS
June 1999
Note: The tool pockets in these tool changers are very close together and will
accommodate "normal" size tools. If "large" tools are needed (meaning that
when placed in the pocket, they will extend beyond the space allowed) then the
pocket on either side must remain empty. Pockets can be designed to hold
large tools as described in the POCKET AND TOOL screen in the Offsets
display.
Faults which are cause by the carousel will not generate an alarm until an M6 (tool change) is
commanded.
POWER U P P ROCEDURE
1. Press the Green power On button and wait for the control to complete the boot up process.
2. Press the Power Up/ Restart button and wait for the machine to perform a Zero Return.
Setting 81 TOOL AT POWERDOWN will cause one of the following actions to occur during power up:
A. If Setting 81 TOOL AT POWERDOWN contains zero the carousel will be rotated to pocket #1. No
tool change will be performed.
B. If Setting 81 contains a number greater than zero, the tool is listed in the pocket and tool table,
and the tool is already in the spindle. Then the carousel will remain at the same pocket and no tool
change will be performed.
C. If Setting 81 contains a number greater than zero, the tool is listed in the pocket and tool table,
and the tool is not already in the spindle. Then the carousel will be rotated to pocket #1, then to
the pocket containing the tool specified by Setting 81 and a tool change will be performed that
results in that tool in the spindle.
