44
6
7
8
2-4
2-4
8-1
8-2
6-2
12-5
12-5
12-2
6-1
2-3
2-3
2-1
2-1
KIT 12: THE HEAD AND SKULL
Take the lower jaw
assembly 2-1, which was
last worked upon in kit 8,
and carefully remove the
Lower Laterals Jaws A
2-3 and B and 2-4.
The lower jaw assembly 2-1 is fitted
within the front part of the Head
6-1/8-1. Fit the tabs on the Lower
Jaw Piece 12-2 into the slots in the
Washers 6-2 and 8-2 and secure
in place with two 2.3x6mm screws
12-5. The tabs on the ends of part
12-2 may need to be rotated to fit.
The side panels 2-3 and 2-4 can
now be attached permanently to skull
part 2-1. Insert the pegs on parts
2-3 and 2-4 into the corresponding
holes in part 2-1 and glue in place.
