Table Size 820 x 240mm
Column Type Ø 115mm
Spindle Taper 3MT
Longitudinal Travel (X-Axis) 540mm
Cross Travel (Y-Axis) 190mm
Vertical Travel (Z-Axis) 410mm
Type of Slides Dovetail
Spindle to Table 455mm
Quill Travel / Diameter 130mm / 75mm
roat Depth (max) 202mm
Tilting Head (Le~Right) Fixed
Tilting Head (Front~Back)) Fixed
Drilling Capacity 31.5mm
End Mill Capacity 22mm
Face Mill Capacity 80mml
Power Feed~Longitudinal (X-Axis) Optional
Table T-Slot 14mm
Work Table Load Capacity 50kg
Spindle Speeds (Steps/RPM) 12 (100~2150)
Motor Power 1.5kW / 2hp
Motor Voltage 240Volts
Overall Height 1100mm
Weight 295kgs
1.1. SPECIFICATIONS....
1.2. STANDARD EQUIPMENT
Drill Chuck & Arbour
3MT ~ 2MT Drill Sleeve
Face Cutter and Arbour
3” Tilt Vice
Safety Cutter Guard
