TA 1100
Power Rating: 1kHz,0.1% THD
50 wpc into 4Ω
40 wpc into 8Ω
Frequency Response: ± 0.1dB,20Hz to 20kHz
+0/-3dB,1.0Hz to 100kHz
Slew Rate: 20V/µs
Input Sensitivity for rated output power:
Unbalanced:0.640V RMS (8Ω),
0.510V (4Ω)Balanced:0.320V (8Ω),
0.250V (4Ω) per phase
Power Consumption: 40VA quiescent
Specifications
546 SOUTH ROCKFORD DRIVE TEMPE, ARIZONA 85281 U.S.A. / 1-866-GOHAFLER WWW.HAFLER.COM
TA1100/TA1600
Signal-to-Noise: >102dB below rated output “A”weighted
CMRR: >65dB at 1kHz
Input Impedance: 47kΩ per phase balanced
47kΩ unbalanced
Gain: 29dB maximum
Damping Factor: 350 (to 1kHz);150 (to 10kHz);18 (to 100kHz)
Controls & Switches: Front Panel:Power Switch and Level Controls
Indicators: Power Lamp,Clip/Thermal/Protect LEDs
Connectors: Input:Balanced:1/4”Tip Ring Sleeve
Unbalanced RCA
Output:1/4”Phone,Spring Clip
Headphone:1/4”
Power:IEC 320
Dimensions: 19”W x 8 1/2”D x 3 1/2”H (2 rack space)
(48cm x 25cm x 8.9cm)
Net Weight: 22 lbs (9.98kg)
TA 1600
Power Rating: 1kHz,0.1% THD
75 wpc into 4Ω
60 wpc into 8Ω
Frequency Response: ± 0.1dB,20Hz to 20kHz
+0/-3dB,1.0Hz to 300kHz
Slew Rate: 100V/µs
Input Sensitivity for rated output power:
Unbalanced:0.780V RMS
(8Ω), 0.620V (4Ω)
Balanced:0.390V (8Ω),
0.310V (4Ω) per phase
Power Consumption: 60VA quiescent
