hager
"DALI Gateway C00Cx2" software
Functional description
Seite 60 von 130
Setting switching status feedback on return of bus/ mains voltage or after programming with
the ETS
If used as an active message object, the switching status feedback information is transmitted to the bus
after bus voltage return or after programming with the ETS. In these cases, the feedback telegram can
be time-delayed with the delay being preset globally for all DALI groups together (cf. "Delay after bus/
mains voltage return").
Set the "Time delay for feedback telegram after bus voltage return" parameter in the "Groups - [x]
groupname - switching" to "Yes".
The switching status telegram transmission will be delayed after bus/ mains voltage return or after
programming with the ETS. No feedback telegram is transmitted during a running delay time, even if
the switching state changes during this delay.
Set the "Time delay for feedback telegram after bus voltage return" parameter in the "Groups - [x]
groupname - switching" to "No".
The feedback switching status telegram will be transmitted immediately after bus/ mains voltage
return or after programming with the ETS.
Setting the cyclical transmission function for the switching status feedback telegram
In addition to being transmitted in case of an update, the switching status feedback telegram can also
be transmitted cyclically via the active message object.
Set the “Cyclical transmission of feedback telegram?” parameter in the "Groups - [x] group name -
switching" to „Yes“.
Cyclical transmission is now activated.
Set the “Cyclical transmission of feedback telegram?” parameter in the "Groups - [x] group name -
switching" to „No“.
Cyclical transmission is now deactivated which means that a feedback telegram is transmitted to the
bus only if one of the switching states has been updated.
• The cycle time is defined centrally for all DALI groups in the “Groups” parameter node.
• During an active delay time, no feedback telegram will be transmitted even if a switching state has
changed.
