hager XEV1K07T2 User Manual

ss
09
Appendix
LED displays for faults
witty charging station
LED display Signal Causes Solutions
1 x − The charging cable connected to the Mode 3 socket
outlet is defective or not compatible, or
− There has been a failure due to a short circuit, the
exchange of control signals between the charging
station and the electric vehicle has been interrupted
•
Replace the charging cable.
2 x − The RFID card has not been recognised
•
Repeat the procedure.
•
Have the RFID card enabled.
− The vehicle has not been recognised
•
Replace the charging cable.
If the problem persists:
•
Check the vehicle and charging station
connections.
•
Contact the vehicle dealer.
3 x − The vehicle’s power consumption is too high, or
− The temperature in the device is too high
(ventilation), or
− There is a communication error between the electric
vehicle and charging station
•
Disconnect the charging station from the
electric vehicle, ventilate if necessary,
and
•
Repeat the charging operation.
If the problem persists:
•
Contact the vehicle dealer.
3 x / 8 x
[6]
− A rated fault current of 6 mA DC has been detected
•
Contact the vehicle dealer.
4 x − There is a local communication problem with the
Ethernet/WiFi
[6]
•
Check the network connections.
•
Ensure that a DHCP router is available in
the network.
− There is a communication error with the internal
energy meter, the charging station is not compatible
with the vehicle
•
Use a compatible charging station.
5 x − The charging operation has been interrupted due to
the temperature being too high
− Shorten the charging operation, as the power supply
via the house connection is insucient
− The protection switch for the Mode 2 socket outlet
current circuit has been triggered
[2]
•
Correct the fault.
6 x − The charging station cannot connect to the vehicle
correctly. The charging operation cannot be started.
•
Replace the charging cable.
If the problem persists:
•
Contact Hager Technical Support if
necessary.
− The RFID reader has failed
− The hardware is defective or incorrectly connected/
configured
•
Contact the charging station installer.
•
Contact Hager Technical Support if
necessary.
There is a critical error, such as:
− The RFID reader has failed, or
− The hardware is defective or incorrectly connected/
configured
•
Arrange for a qualified electrician to
identify and remedy the fault.
•
Contact Hager Technical Support if
necessary.
