40
″
LCD
TV
Haier
40D3505T-40D2500
34
7. OSD is unstable or can’t
work normally
Key board connected properly?
Reconnect the key board
Buttons are OK?
Replace the button function
Ye
s
No
Key board is OK?
Replace the key board
Replace the main board
No
Ye
s
No
No
OSD is unstable or can’t work normally
Enter factory mode to do “Reset”
Ye
s
33
35
Table of Contents
Default Chapter
1
Table of Contents
1
Important Safety Notice
2
Revision List
3
1 General Specification
4
2 Operating Instructions
8
Remote Control
8
OSD Menus
10
Panel Control and Rear Terminal Control
12
3 Input/Output Specification
23
4 Mechanical Instructions
25
5 Repair Flow Chart
28
6 PCB Layout
35
Main Board
35
Power Board
37
IR Board
40
Keyboard
40
7 Adjustment
41
ADC/WB Adjustment
41
Firmware and DDC Instruction
42
8 Block Diagram
46
9 Wiring Diagram
48
10 Schematic Diagram
49
Main Board
49
Power Board
56
IR Board
58
Key Board
59
