5.2.5.. Electrical Control Functions For Cassette and Convertible type
1. Dip switch functions:
1.1 SW01 detailed definition is as following:
SW01
[1] [2] [3] [4] [5] [6] [7] [8]
Function
-- -- -- -- -
-- -- -- -- --
----
-- -- -- -- --
-- -- -- -- -- -- -- 0
Passive contact valid
-- -- -- -- -- -- -- 1
Passive contact invalid
-- -- -- -- -- -- 0 --
To set indoor address(by
remote/wired controller)
-- -- -- -- -- -- 1 --
To set indoor address(by dip
switch)
-- -- -- -- -- 0 -- --
AC 3-speed motor
-- -- -- -- -- 1 -- --
AC stepless motor
-- -- -- -- 0 -- -- --
Pre-set
-- -- -- -- 1 -- -- --
Pre-set
1.2 SW02 detailed definition is as following:
SW02
[1] [2] [3] [4] [5] [6] [7] [8]
Function
――
0 0 0 0 0 0 0
Central control address=1
――
0 0 0 0 0 0 1
Central control address =2
----
----
――
1 1 1 1 1 1 1
Central control address =128
0
Allow to set central control
address
1
Forbid to set central control
address
1.3 SW03 detailed definition is as following:
SW03
[1] [2] [3] [4] [5] [6] [7] [8]
Function
-- -- -- -- --
-- -- -- -- --
-- -- -- -- --
-- -- -- -- --
-- -- -- -- --
-- -- -- -- --
-- -- -- -- --
-- -- -- -- --
-- -- -- 0 -- -- -- --
Remote control unit
-- -- -- 1 -- -- -- --
Wired control unit
-- -- -- -- 0 -- -- --
Display cooling only on wired controller(Dry, Cool,
Fan)
-- -- -- -- 1 -- -- --
Display heat pump on wired controller(Cool, Heat etc)
A
