Item Model AB35S2SC1FA
Function —— Cooling Heating
Capacity W 3500 4000
Sensible heat ratio W 0.71 /
Dehumidifying capacity 10-³xm³/h 1.5
Indoor unit
Power supply 1PH, 220-240V~, 50/60Hz
Fan
Type × Number —— Centrifugal*1
Speed(H-M-L) r/min 690/620/560/500
Fan motor output/input power W 10/15
Air-ows (H-M-L) m³/h 620/520/450/350
Heat exchanger
Type / Diameter mm Inner grooved pipe/φ7.0
Row —— 2
Total area m² 0.544
Temp.scope °C 2.0-7.0
Dimension
(LxWxH)
External mmxmmxmm 570*570*260
Package mmxmmxmm 718*680*380
Drainage pipe (Material,I.D/O.D) mm PVC 26/32
Control type(Remote/Wired) Remote YR-HBS01(O) or Wired YR-E17(O)
Fresh air hole dimension mm 95
Electricity Heater kW None
Noise level
(H-M-L)
Sound power level dB(A) 52
Sound pressure level dB(A) 36/33/30/27
Weight(Net/Shipping) kg/kg 18.5/22
Panel
Panel model(Color) PB-700IB(White)
Dimension
External(L*W*H) mmxmmxmm 700*700*60
Package(L*W*H) mmxmmxmm 740*750*115
Weight(Net/Shipping) kg/kg 2.8/4.8
Piping
Refrigerant Type R32
Pipe
Liquid mm Φ6.35(1/4)
Gas mm Φ9.52(3/8)
Connecting method Flared
Norminal condition: indoor temperature (cooling): 27°CDB/19°CWB, indoor temperature (heating): 20°CDB
Outdoor temperature(cooling): 35°CDB/24°CWB, outdoor temperature(heating): 7°CDB/6°CWB
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated sound
intensity meter.
