Haier AFD626TGB/F

SERVICE MANUAL
Model:AFD626TGW/R/B
7
Issue 2010-10-25
Rev. Ref1010S025V0
Vegetable Crisper
2-10°C 2-10°C 2-10°C
Freezer
-16 ~-26°C -16 ~-26°C -16 ~-26°C
Features:
Energy consumption per l 100 net / year
kWh 102 102 102
Energy consumption per l 100 net / 24h
kWh 0.28 0.28 0.28
Cooling system: K=Compressor / A=Absorption
K K K
Max noise level
dB(A
)
42 42 42
4
Aesthetics
Colors: W=white G=silver gray
B=Obsidian SS=stainless steel
W BLACK RED
Fascia panel / Handle (w / c)
G/G G/G G/G
F= flat / R= rounded / S= streamline
R R R
Inside colour
w w w
Compartments number
n° 3 3 3
Bottle compartment
n° 4 4 4
Hinged (r =right l =left) / reversible
r / X r / X r / X
Shelves:
Number Fridge / Freezer
3 / - 3 / - 3 / -
Type (gr=grill / g=glass / p=plastic)
g g g
Color w-white / b=blue / t=transparent.
t t t
Adjustable (Y=yes / N=not)
N N N
Foldable Shelf
yes yes yes
Bottle Rack
yes yes yes
Drawers:
Plastic drawers (fully freezing comp.)
n°. 3 3 3
Muti-use comp
n°. 2 2 2
Colour of drawer (w=white/t=transp./g=green)
t t t
Crisper:
Chiller / Meat (salad crisper) transparent / white
Chiller (t) Chiller (t) Chiller (t)
Vegetable crisper(s) transparent / white
t t t
5
Equipment & accessories
Control panel
Interior / exterior
Exterior Exterior Exterior
Thermometer interior / exterior
Interior Interior Interior
Display type
LCD LCD LCD
Control lamps green / yellow /white
W W W
Over temperature alarm LED / acoustic acoustic acoustic acoustic
Adjustable thermostat
yes yes yes
Fast freeze switch /-function
yes yes yes
Deodorizing
yes yes yes
Interior light
W yes yes yes
LED light
n° Full Full Full
