Haier AFD626TGB/F

SERVICE MANUAL
Model:AFD626TGW/R/B
8
Issue 2010-10-25
Rev. Ref1010S025V0
Freeze pack(s)
n° 3 3 3
ice maker Manual/ Automatic
M M M
Ice cube tray(s)
n° 1 1 1
Butter holder
yes yes yes
Egg trays
2 2 2
Adjustable feet front / rear
n° 2 / - 2 / - 2 / -
Length of cable/incl. plug
cm 200 200 200
Condenser Back wall / Integrated
I I I
6
Product dimensions
Unit dimensions ( H / W / D)
cm 180/63/64 180/63/64 180/63/64
Depth Without handle
cm 64 64 64
Depth with open door
cm 119 119 119
Door open angle
n° <135 <135 <135
Net weight
kg 78 78 78
7
Packing dimensions & load ability
Packing dimensions (H / W / D)
cm 185.5/74.7/71.4 185.5/74.7/71.4 185.5/74.7/71.4
Gross weight
kg 92 92 92
40 ' Container load
pcs 54 54 54
40 ' HC Container load
pcs 72 72 72
8
Recycling symbols
Packing materials / Recycling symbols (RS)
RS RS RS RS
Carton weight in gr
6270 6270 6270
Polystyrene weight in gr
06 2570 2570 2570
Polyethylene foil weight in gr
04 210 210 210
9
Service
Users instruction (languages)
D / F / I / GB / E / P / NL
2-2. Main functions and features
◆ Full-frequency technology.
◆ Artificial intelligent automatic regulation of the temperature.
◆ Over-temperature alarm.
◆ Full temperature range of the variable temperature compartment
◆ LCD display.
◆ Holiday function.
