14. Air velocity and distribution
m
Fig 1
top view
flow control panel horizal
lourer:center
Fig 3
top view
flow control panel horizontal
lourer:center
0.25
0.5
1.0
2.0
Fig 4
top view
flow control panel vertical
lourer:center
Condition
Fan speed:high
Operation mode:fan
Voltage:230V,50Hz
Fig 2
top view
flow control panel horizontal
lourer:right and left
