Removal Procedure
10 Domestic air conditioner
Step Procedure Points
4
Loosen the marked
screws (7EA).
And then Remove the
heat exchanger
Remove Fan Motor
1
Loosen the marked
screws(4EA) and
release the cover of
fan motor
