Removal Procedure
11 Domestic air conditioner
Step
Procedure Points
1
2
Loosen the
marked
screw (2EA) of fan
motor up bracket and
remove it
Loosen the marked
screw (1EA) of fan
motor and remove fan
motor
ove it
Screw of fan rotor
Screw of Fan Motor
up bracket
Fan motor bracket
(
UP
)
Fan motor ass
y
