Haier AU84NXTBAA - Installation Diagrams

Gas line
Liquid line
3) Quattro combination
A1
B1
A2
B2
A1/A2 B1/B2
Model
Gas pipe
Liquid pipe
28000BTU
15.88mm
9.52mm
28000BTU
15.88mm
9.52mm
Indoor
unit
2) Trio combination
A1
B1
Model
Gas pipe
Liquid pipe
28000BTU
15.88mm
9.52mm
42000BTU
19.05mm
9.52mm
A1
B1
A2
A2
28000BTU
15.88mm
9.52mm
Indoor
unit
1) Duo combination
A1
B1
A1 B1
Model
Gas pipe
Liquid pipe
42000BTU
19.05mm
9.52mm
42000BTU
19.05mm
9.52mm
Indoor
unit
1. Combination instructions
Installation diagrams
