In installation, please check specially the below items:
• If the connected units quantity and the total capacity is in the allowable range?
• If the refrigerant pipe length is in the limited range?
• If the pipe size is proper? And if the pipe is installed horizontally?
• If the branch pipe is installed horinzontally or vertically?
• If the additional refrigerant is counted correctly and weighed by the standard balance?
• If there is refrigerant leakage?
• If all the indoor power supplies can be on/off simultaneously?
• If the power voltage is in compliance with the data marked on the rating label?
• If the address of indoors and outdoors has been set?
Before installation
1) Before installation, check if the model, power supply, pipe, wires and parts purchased respectively are correct.
2) Check if the indoors and outdoors can be combined as the following.
Installation instruction
Indoor
Gather pipe
Combined
capacity
range
HP
Capacity
(W)
Combination Type
Allow the most
connected
indoor units
The most
recommended
indoor unit
number
Total indoor
capacity(100W)
8 25200 single 15 8 126~328 -
50%~130%
10 28000 single 17 10 140~364 -
12 33500 single 20 11 168~436 -
14 40000 single 24 13 200~520 -
16 45000 single 27 15 225~585 -
18 50400 single 30 17 252~655 -
20 56000 single 33 18 280~728 -
22 61500 single 36 20 308~800 -
24 68000 single 40 22 340~884 -
26 73500 single 43 24 368~956 -
28 80000 combination(14+14) 47 26 400~1040 -
30 85000 combination(14+16) 50 28 425~1105
HZG-20B
32 90000 combination(16+16) 53 30 450~1170
34 95400 combination(16+18) 56 31 477~1240
36 100800 combination(18+18) 59 33 504~1310
38 106400 combination(18+20) 63 35 532~1383
40 112000 combination(20+20) 66 38 560~1456
42 117500 combination(20+22) 69 42 588~1528
44 123000 combination(22+22) 72 44 620~1612
46 129500 combination(22+24) 76 46 648~1684
48 136000 combination(24+24) 80 49 680~1768
50 141500 combination(24+26) 83 51 707~1840
52 147000 combination(26+26) 86 52 735~1911
54 151200 combination(18+18+18) 89 54 756~1966
56 156800 combination(18+18+20) 92 59 784~2038
