Haier HB21FSSAA User Manual

Disassembly and Assembly of Door
9
Refr. Left Door Disassembly and Assembly
③ Remove the left door and place it to proper
location.
⑤ The door can be installed by reverse steps.
④ Middle hinge may be removed if necessary.
Disassembly and Assembly of Ice
Receiving Drawer
① Pull the drawer to the maximum length at first,
and then remove the drawer.
② The Ice Receiving Drawer can be install by
reverse steps.
Disassembly and Assembly of Freezer
Drawer
① Pull the freezer door to the maximum length at
first, and then remove the drawer.
② The freezer larger drawer can be installed by
reverse steps.
Preparation
① Remove all package
Packing base and tapes that fix accessories also must be removed.
② Check out the accessories and materials
Check out the items in the box according to the packing list. If varies, please make query to the seller.
③ Place your refrigerator into proper location
④ It is better to clean your refrigerator before use (see section “Cleaning” for details)
⑤ Standing
After leveling and cleaning, the refrigerator shall keep standing more than 6 hours before
connecting to power supply to ensure the normal running of the refrigerator.
Downloaded from www.vandenborre.be

Haier HB21FSSAA Specifications

General

Icemaker	No
Noise level	42 dB
Climate class	SN-T
Total net capacity	543 L
Total gross capacity	635 L
Child lock	-
Product color	Stainless steel
Built-in display	Yes
Appliance placement	Freestanding
Number of compressors	1
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	10 kg/24h
Freezer net capacity	149 L
Freezer gross capacity	- L
Freezer number of shelves/baskets	2
Storage time during power failure	12 h
Fridge net capacity	394 L
Fridge number of shelves/baskets	3
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Annual energy consumption	432 kWh
Package depth	760 mm
Package width	980 mm
Package height	1860 mm
Package weight	161000 g

Weight and Dimensions

Depth	770 mm
Width	910 mm
Height	1780 mm
Weight	141000 g
