11 If storage space needs to be increased
Users can remove parts of the appliance to achieve the purpose
of increasing the storage space of the appliance.
The following is a list of detachable parts. The detachable parts
areasshownintherightfigure
For detailed disassembly methods, please see "Disassembling
and cleaning the parts" on page 21.
Number Name of part
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
Bottle holder (upper left)
Bottle holder (middle left)
Bottle holder(lower left)
Bottle holder (upper right)
Bottle holder (middle right)
Bottle holder (lower right)
Shelf (upper)
Shelf (lower)
Fruit & Vege box cover
plate
Fruit & Vege box (left)
Fruit & Vege box (right)
MY ZONE (left)
MY ZONE (right)
Fruit & Vege compartment
tray
MY ZONE
Automatic icemaker
Small freezer drawer
Small freezer drawer tray
Pull-out box (left)
Pull-out box (right)
Pull-out tray
Gear connecting rod
Detachable part
Detachable part (concealed)
3
1
2
4
5
6
7
8
9
12 13
10 11
14
15
16
19 20
18
17
21
22
3

Haier HB26FSSAAA Specifications

General

Control type	Touch
Display type	LED
Product color	Silver, Titanium
Product design	French door
Built-in display	Yes
Door gasket type	Snap-in gasket
Reversible doors	No
Shelves material	Glass
Shelf finish type	Chrome frame
Appliance placement	Freestanding
Fridge net capacity	484 L
Number of egg balconies	1
Fridge number of shelves/baskets	3
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	14 kg/24h
Freezer net capacity	266 L
Storage time during power failure	20 h
Fresh zone compartment net capacity	30 L
Current	2 A
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Annual energy consumption	386 kWh
Control position	Internal
Noise level	39 dB
Climate class	SN
Cooling system	Dynamic (fan-assisted)
Total net capacity	750 L
Package width	1091 mm
Package height	851 mm
Package weight	204000 g

Weight and Dimensions

Depth	760 mm
Width	1005 mm
Height	1900 mm
Weight	189000 g
