68
10.4 IR Board
715T3294 1
IRRV
056G 627503
C02
NC/4.7uF/16V
33T8032 5F HR
081G 14 24 GP
C01
0.1uF/16V
BLUE
VOUT
1
GND
2
VCC
3
U01
GP18B38BCE-HB
VCC
R01 15K OHM 1/10W
RED
1
2
3
4
5
CN01
CONN
1
23
4
RED
BLUE
LED01
LED
LED_B
LED_R
