32
Components List
Subassembly
Spare
parts
number
Location
No.
Spare Parts Name in
English
Specification Qty
Back Cover
Subassembly
Back Cover Subassembly 1
Back Cover Assembly 1
Back Cover 1
Button Bracket 1
DVD Control Board bracket 1
Power Board bracket 2
Terminal Board 1
LCD panel bracket 2
Small cover board 1
Bolster 1
Screw 2
DVD shield metal 1
DVD Button Label
Sponge Strip 0.17
Bolt 2
Bolt GB818-85 M3*4 4
