Haier HLP141E User Manual

English
14
3. Set Cycle and Start
To start drying a laundry load using Auto Dry with presets for Temperature
and Time, there are 3 easy steps:
4. Cooling Status.
When ‘Cooling’ Status LED is ON, the Cooling down time takes 10 minutes
for dryer along with the garments.
If you want to take out clothes in the middle of drying cycle, please use
caution and carefully take out the HOT clothes.
5. End Dry Cycle
A beeper alarm alerts you when the Drying Cycle ends, then the dryer will
power off. Take out the clothes as soon as possible.
6. Clean Filter
‘Clean Filter’ Status LED reminder goes ON. After drying each load of
clothing, always clean the lint filters.
1. Turn ‘Power ON’ 2. Choose drying Cycle –
Normal, Heavy or Delicate
3. Press ‘Start’
Power
On/Off
Cycles
Start
Pause
Cycles
Dry
Time
Temp
Start
Pause
Power
On/Off
Dry
Cooling
End Cycle
Clean Filter
Normal
Timed Dry
Heavy
Delicate
30
60
90
120
High
Low
Air-Dry
150
Status
A
U
T
O
D
R
Y
2 3 1
Note
Normal , Heavy and Delicate Cycles are auto-set for Temperature and Time to dry
a regular load. Timed Dry Cycle is for manual selecting Dry times and Tempera-
tures. (See next page for instructions)
Exhaust Vent
Casing

Haier HLP141E Specifications

General

Door hinge	Left
Control type	Buttons
Loading type	Front-load
Drying system	Vented
Product color	White
Built-in display	No
Appliance placement	Freestanding
Heat source	Electric
AC input voltage	120 V
AC input frequency	60 Hz
Energy consumption	- kWh
Energy efficiency class	-
Cycle time	150 min
Noise level	- dB
Drum capacity	- kg
Number of drying programs	4

Weight and Dimensions

Depth	631 mm
Width	425 mm
Height	685 mm
Weight	25990 g
