English
18
CARE AND CLEANING GUIDE
Clean buildup such as lint on filters after each use, otherwise it will affect the
performance of your dryer.
Cleaning of Lint Trap and Filters
The lint filter must be always used for drying.•
It must be cleaned each time before or after each use.•
1. Remove the Exhaust venting casing
containing the filters.
Use four finger grabbing holes in middle of the
exhaust vent casing center to pull from the drum.
Remove the filters by pulling straight out.
The exhaust vent casing contains the ‘Lint
filter’ and ‘Exhaust filter’, as shown in figure 1.
2. Cleaning the filters from lint
Separate ‘exhaust vent casing’,’lint filter’ and ‘exhaust
filter’ and clean the lint off the filter and exhaust filter
with a soft brush or a small vacuum cleaner. (as shown
in figure 2) or wash it with water if still dirty.
Dry completely before use and do not damage the filters.
3. Install the filters
After cleaning the filters, assemble filters in the
order of ‘exhaust vent casing’,’lint filter’ and
‘exhaust filter’ (as shown in figure 3).
4. Align the recesses center of the ‘exhaust vent
casing’ to the center of drum and make sure that
it is firmly inserted.
Please unplug the power cord when cleaning the Dryer.•
Clean the interior drum or dryer housing with a damp soft cloth.•
NEVER USE YOUR DRYER WITHOUT
THE LINT FILTERS INSTALLED.
Do not put water directly on dryer.•
Do not use thinner, gasolene or alcohol.•
Do not use any type of spray cleaner to clean the interior.•
Remove everything from drum before drying the next load.•
Clean cabinet with mild soap and water only. Do not use •
harsh or abrasive cleaners, as this could damage the dryer.
WARNING!
WARNING!
Figure 2
Figure 3
Exhaust
vent casing
The filter is in the rear
of the drum
Figure 1
Lint
filter
Exhaust
filter
Lint Filter Exhaust Filter Small Vacuum
cleaner
Brush Lint
Exhaust
vent casing
To Next Page
