Haier HLP141E User Manual

English
7
Assemble Dryer for Installation
Screw mounting hook bracket and wall spacer to dryer with screws provided.
1. Attach Hanging hook bracket
using the 4 screws.
3. Attach Exhaust Housing. Connect vent housing to dryer using hose clamp
provided to the exhaust pipe.
4. You have two choices of the exhaust pipe housing direction.
2. Attach the 2 wall spacers to the bottom
of the dryer, using the 2 screws.
Spacers
Exhaust Vent Housing
Hose Clam
Exhaust Pipe

Haier HLP141E Specifications

General

Door hinge	Left
Control type	Buttons
Loading type	Front-load
Drying system	Vented
Product color	White
Built-in display	No
Appliance placement	Freestanding
Heat source	Electric
AC input voltage	120 V
AC input frequency	60 Hz
Energy consumption	- kWh
Energy efficiency class	-
Cycle time	150 min
Noise level	- dB
Drum capacity	- kg
Number of drying programs	4

Weight and Dimensions

Depth	631 mm
Width	425 mm
Height	685 mm
Weight	25990 g
