13
English
Installing the Lint Filter
The lint filter must be installed before the washer is used.
The lint filter is packaged with the User Manual.
Leveling the Washer
Your washer has an adjustable leveling leg that is located on the front right cor-
ner. After properly placing your washer in its final location, you may level the
washer.
• Loosen the adjustable nut. The leveling leg can be
adjusted by turning it counter-clockwise to raise the
washer and clockwise to lower the washer.
Note: If the washer is inclined more than 2˚, the machine
will not operate.
Installing Your Washer
Read the installation instructions carefully before beginning.
1. Connect the water inlet hose to the water faucet.
Note: The ends of the inlet hose are clearly marked to install the hoses to the
correct inlet.
2. Connect the other ends to the washer inlet located at the top rear of the
machine. Insert a new flat washer (provided) to each end of the inlet hose.
3. The drain hose must be placed into a drainpipe or sink at least 1-1/2 inches
in diameter. Use the gooseneck drain hook to hold the hose in place. To avoid
possible water back-up, the drain hose must reach a height of at least 31-1/2
inches minimum and 40 inches maximum.
4. Plug in the washer to a regular 110-120 Volt / 60 Hz, 15 Amps outlet.
Note: Carefully inspect for any leaks around the machine and at the back. If there
is a leak, check if any connections are loose. You may need to tighten any
loose connections. Do not remove the water absorption cushion. Check
before each use to make sure it is not damaged.
CAUTION! If after completing these steps you are still unsure whether unit has been
properly installed, contact a qualified installer. We recommend that the
washer be installed by a certified technician to ensure that it is
properly installed.
