Refrigerator: (see fig. # 5)
1. Remove screw cover from the handle.
2. Using a phillips head screwdriver, remove both screws
from the side of the refrigerator door that holds the handle.
3. Install the handle on the opposite side.
4. Remove screw plugs.
5. Install the screws and screw covers to their corresponding position.
Reversing Freezer Door: (see fig. # 6)
1. Remove the water-collecting tray.
2. Using a narrow blunt object (e.g. Phillips head screwdriver) press the
hinge axle on the bottom of the hinged side of the freezer door.
3. This will remove the freezer door off its hinges
4. Turn the door around and install hinge on the opposite side.
5. Once the freezer door is installed insert the water-collecting tray.
Reversing the Door Handles
fig. # 5a
fig. # 5
fig. # 6a
fig. # 6
hinge
axle
water collection
tray
10
