Haier HW60-1202D Service Manual

SERVICE MANUAL
Front Load Washing Machine
1 2 345 6 7 Average
standard
deviation
data of cycle yr.m.d
2011-2-14 2011-2-14 2011-2-15 2011-2-15 2011-2-16 2011-2-17 200-2-18
Base Load
Part A Part B Part B Part A Full load Full load Full load
Measured Programme
cotton 40℃ cotton60℃ cotton40℃ cotton60℃
Main wash cold water
consumption
L 10.6 11.2 11.3 11.4 15.1 15.7 15.1 12.9 2.255
Main wash hot water consumption L
Total hot water onsumption L
Total cold water onsumption L 31.8 33.8 33.5 34.4 45.4 46.5 44.5 38.6 6.537
Total water onsumption L 31.8 33.8 33.5 34.4 45.4 46.5 44.5 38.6 6.537
Unit water consumption L/kg 5.3 5.6 5.6 5.7 7.6 7.8 7.4 6.4 1.089
Annual water consumption for
total 220 cycles （（AWc））
L
Main wash duration min 123 144 123 144 145 140 140 137 9.764
Heating time min 12 21 11 22 22 23 23 19 5.273
Programme time min 152 171 153 171 174 174 174 167 10.000
Electrical energy consumption
（
for programme）
kWh 0.562 0.876 0.557 0.878 0.865 0.904 0.881 0.79 0.157
Total cold water correction energy kWh 0.006 0.007 0.007 0.007 0.009 0.018 0.014 0.010 0.005
Total hot water correction energy kWh
Total energy consumption（
Wt） kWh 0.568 0.883 0.564 0.885 0.874 0.922 0.895 0.799 0.160
Unit energy consumption Kwh/kg 0.095 0.147 0.094 0.147 0.146 0.154 0.149 0.133 0.027
Energy consumption for (LU) kwh
Energy consumption for (LO) kwh
Energy consumption for （
O） kwh
Energy consumption for
programme running
kwh
kwh
Energy consumption for SAEc kwh
Energy Efficiency Index
%
A+++ A++ A+ A
B C D
Energy Efficiency Class
8483
AEc
SAEc
EEI
=
=
=
0.08
=
=
3.06
3.07
54.5
Energy consumption for single Low power mode in total 220 cycles
175.68
Annual energy consumption for
total 220 cycles （
AEc）
181.89
Energy consumption for total 220 cycles
=Wt*220
333.70
=
Energy labelling for electrical clothes washing machines for household use
Cycle data,parameters and results
N/A
cotton60℃
Cycle:
HW70-1202D HW60-1202D
HW60-1002D HW50-1202D
HW60-1202D
7

Haier HW60-1202D Specifications

General

Door hinge	Left
Drum volume	39 L
Control type	Buttons, Rotary
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Door opening angle	180 °
Appliance placement	Freestanding
Half-load	-
Drum capacity	6 kg
Cycle time (max)	168 min
Delay start (max)	24 h
Residual moisture	64 %
Spin-drying class	B
Maximum spin speed	1200 RPM
Minimum spin speed	400 RPM
Noise level (spin)	72 dB
Noise level (wash)	56 dB
Number of washing programs	11
Washing class	A
Annual water consumption washing	8483 L
Annual energy consumption washing	182 kWh
Current	10 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (typical)	2000 W
Water consumption per cycle	- L
Energy consumption washing per cycle	0.895 kWh
Package weight	67000 g

Weight and Dimensions

Depth	520 mm
Width	595 mm
Height	850 mm
Weight	65000 g
Door diameter	320 mm
