2.NT68565
Function:Flat Panel Monitor Controller
1 AGND TMDS Analog GND
2 RX2+ TMDS input channel 2+
3 RX2- TMDS input channel 2-
4 AVCC TMDS Analog VCC must be set to 3.3V
5 RX1+ TMDS input channel 1+
6 RX1- TMDS input channel 1-
7 AGND TMDS Analog GND
8 RX0+ TMDS input channel 0+
9 RX0- TMDS input channel 0-
10 AGND TMDS Analog GND
11 RXC+ TMDS input clock pair
12 RXC- TMDS input clock pair
13 AVCC TMDS Analog VCC must be set to 3.3V
14 REXT External termination resistor
15 PVCC TMDS PLL Analog VCC must be set to 3.3V
16 PGND TMDS PLL Analog GND
17 NC \
18 NC \
19 BVMID B channel Midscale clamp voltage bypass
20 BIN1+/ Pb1+ Analog Port 1 B/Pb channel positive analog video input
21 BIN1-/ Pb1- Analog Port 1 B/Pb channel negative analog video input
22 SOGI1/ SOY1 Analog Port 1 Sync On Green Input with Schmitt trigger
23 GIN1+/ Y1+ Analog Port 1 G/Y channel positive analog video input
24 GIN1-/ Y1- Analog Port 1 G/Y channel negative analog video input
25 RIN1+/ Pr1+ Analog Port 1 R/Pr channel positive analog video input
26 RIN1-/ Pr1- Analog Port 1 R/Pr channel negative analog video input
27 RVMID R channel Midscale clamp voltage bypass
28 ADC_VAA Power ADC Analog power supply
29 ADC_GNDA Power ADC Analog ground
30 BIN0+/ Pb0+ Analog Port 0 B/Pb channel positive analog video input
31 BIN0-/ Pb0- Analog Port 0 B/Pb channel negative analog video input
32 SOGI0 / SOY0 Analog Port 0 Sync On Green Input with Schmitt trigger
33 GIN0+/ Y0+ Analog Port 0 G/Y channel positive analog video input
34 GIN0-/ Y0- Analog Port 0 G/Y channel negative analog video input
35 RIN0+/ Pr0+ Analog Port 0 R/Pr channel positive analog video input
36 RIN0-/ Pr0- Analog Port 0 R/Pr channel negative analog video input
37 NC \
38 NC \
39 HSYNCI1 Analog Port 1 Channel 1 Horizontal Sync Input
40 VSYNCI1/TOUTP Analog Port 1 Channel 1 Vertical Sync Input
41 HSYNCI0 Analog Port 0 Channel 0 Horizontal Sync Input
42 VSYNCI0 Analog Port 0 Channel 0 Vertical Sync Input
43 PLL_ GND Core Logic Ground pin for PLL
