Haier L19A11W Service Manual

44
TCLK Reference
clock Input Reference clock Input
45 PLL_ VDD Core logic power supply (1.8V) pin for PLL
46 HDCP_SDA For DVI HDCP communication interface Serial Data In/Out
47 HDCP_SCL For DVI HDCP communication interface Serial Clock
48 RSTn System Reset
49 SDA Host Interface Serial Data In/Out
50 SCL Host Interface Serial Clock
51 IRQn Interrupt Request
52 CVDD Core logic power supply (1.8V) pin
53 IO_SEL \
54 DVDD Display Digital Power Supply
55 V0 Video data input
56 V1 Video data input
57 V2 Video data input
58 V3 Video data input
59 V4 Video data input
60 V5 Video data input
61 V6 Video data input
62 V7 Video data input
63 VCLK Video Port Clock
64 NC \
65 DGND/CGND Digital Ground/ Core Logic Ground
66 T7P/B0 Display Blue data 0 output
67 T7M/B1 Display Blue data 1 output
68 TCLK2P/B2 Display Blue data 2 output
69 TCLK2M/B3 Display Blue data 3 output
70 T6P/B4 Display Blue data 4 output
71 T6M/B5 Display Blue data 5 output
72 T5P/B6 Display Blue data 6 output
73 T5M/B7 Display Blue data 7 output
74 T4P/G0 Display Green data 0 output
75 T4M/G1 Display Green data 1 output
76 DGND/CGND Digital Ground/ Core Logic Ground
77 NC \
78 NC \
79 T3P/G2 Display Green data 2 output
80 T3M/G3 Display Green data 3 output
81 TCLK1P/G4 Display Green data 4 output
82 TCLK1M/G5 Display Green data 5 output
83 T2P/G6 Display Green data 6 output
84 T2M/G7 Display Green data 7 output
85 T1P/R0 Display Red data 0 output
86 T1M/R1 Display Red data 1 output
87 T0P/R2 Display Red data 2 output
88 T0M/R3 Display Red data 3 output
89 NC \
