Haier L26M3 User Manual

-5-
INSTALLATION
Front panel
KEYBOARD
REAR AV PASTER
All the terminals are(from left to right):
AC POWER SOCKET,
Note: 1.AV1 share one audio channel.
2.When HDMI 1 port get DVI signal, the PC Audio channel is changed to
receive the audio for HDMI 1 port.
HDMI 1, HDMI 2, VGA , YPbPr, AV1, AUDIO INPUT, PC AUDIO INPUT,
ANTENNA.
and YPbPr
1: Remote control sensor.
2: Indicator LED: GREEN POWER ON.
RED STANDBY.
3: Key board
1 2 3
4 5 6
7 8 9 0
+
CH
_
+
_
VOL
30 30
3
1
2
1 SOURCE Display the input source menu.
2 MENU Display main MENU.
3 CH+/CH-:In TV mode press CH+ or CH- to
change the channel up and down.In MENU mode, press
CH+ or CH- to select items .In standby mode,
press CH+ or CH- to turn on the TV.
4 VOL+/VOL-:Adjust sound level.In MENU mode,
press VOL+ or VOL- to adjust the item that you
selected.
5. STANDBY : Press this button to turn the unit ON
from STANDBY mode. Press it again to turn the set
back to STANDBY.
6.USB
7.HEADPHONE
8.VIDEO INPUT
9.AUDIO INPUT-L
10.AUDIO INPUT-R
SOURCE
MENU
CH+
CH-
VOL+
VOL-
STANDBY
R
L
VIDEO
USB
VIDEO
L
R
AV2
HEADPHONE
HEADPHONE
USB
L
R
AV1
Pr
Y
Pb
PC
AUDIO INPUT
RF INPUT
HDMI2 INPUT
HDMI1 INPUT

Haier L26M3 Specifications

General

Brand	Haier
Model	L26M3
Category	LCD TV
Language	English
