Product Introduction
Rear View
Remote Control window(keep clear)
LED indicator
(IR) Infrared Receiver: Receives IR signals from the remote control.
(Power on/Standby) LED indicator: Press to turn on and off.
The effective receiving range for the signal is 5-8 metres from the front of the remote
control window, and 30
0
to the left or right side and 20
0
above or below the control
window.
Indicator on(Red) Standby mode
Indicator on(Green) Power on mode
5
Front View
Connections
See next page
Display/exit the OSD menu.
Scan through channels.
Adjust the volume.
Display the input source menu.
Turn on/standby the TV set.
Product Introduction
AC Power cable- Connect to AC power supply
CH
VOL
CH
VOL
200mm
200mm
To Next Page
