Technical Specifications
Video Encoding
Makito User’s Guide, v2.1.0, Issue 01 261
Supported Video Encoding Resolutions (Makito #B-290E-DVI)
Legend:
“High” resolutions can only be used for the High bandwidth stream.
Resolutions marked “All” may be used for either High or Low bandwidth streams (see
NOTE below).
*Also includes 1/1.001 frame rates such as 23.98, 29.97 and 59.94.
1080p23.98 and 1080p24 resolutions are not supported in Analog Component (Y,Pb,Pr).
Support of 1600x1200 input resolution is not possible.
Table B-1
Makito #B-290E-DVI Available Video Resolutions
Y,Pb,Pr & Y,Cb,Cr TV Input Resolutions /Scan Rates
Output Resolutions
1080p 1080i 720p 480i 480p 576i 576p
Name Resolution
60* / 30* 50 / 25 24* 30* 25 60* 50 30* 60* 25 50
HD 1080 1920x1080 High High
High
High High - - - - - -
3/4 HD 1080 1440x1080 High High
High
High High - - - - - -
1/2 HD 1080 960x1080 All All
All
All All - - - - - -
HD 720 1280x720 High High
High
- - High High - - - -
3/4 HD 720 960x720 - -
-
- - All All - - - -
1/2 HD 720 640x720 - -
-
- - All All - - - -
SD 480 720x480 All -
All
All - All - All All - -
SD 576 720x576 - All
All
- All - All - - All All
4SIF 704x480 - - - - - - - - - - -
4CIF 704x576 - - - - - - - - - - -
3/4 D1 NTSC 540x480 - - - - - - - All All - -
3/4 D1 PAL 540x576 - - - - - - - - - All All
2SIF 704x240 - - - - - - - - - - -
2CIF 704x288 - - - - - - - - - - -
Half-D1 NTSC 352x480 - - - - - - - All All - -
Half-D1 PAL 352x576 - - - - - - - - - All All
SIF 352x240 - - - - - - - - - - -
CIF 352x288 - - - - - - - All All All All
