D. Mode Selection
Select the desired mode using the mode
selection button.
The Hakko 852 provides the following three
modes:
● Manual Mode (See page 8.)
In this mode, air-blow start and vacuum pump operation are
handled entirely by manual operation. Use this mode when
setting up Auto mode conditions, performing operations for
which no conditions have been established, performing
maintenance, or executing a single operation.
● Remove Mode (AUTO) (See page 9.)
This mode is used when removing parts. After starting, the
heating time can be set by setting the timer. The vacuum
pump turns ON automatically.
● Install Mode (AUTO) (See page 10.)
This mode is used when installing parts. After starting, the
heating time can be set by setting the timer. The vacuum
pump turns OFF automatically.
VACUUM MODE
(Figure 9 )
MANUAL
REMOVE
INSTALL
AUTO
7
PREPARATION: ASSEMBLY AND ELECTRICAL CONNECTION
