2. SPECIFICATIONS
Model name HAKKO FG-101B
Temperature Resolution 1˚C 1°F
Measurement range 0 - 700˚C
*1
32 - 1300°F
*1
Measurement
tolerance
±3
˚C
(between 300 and 600
˚C
)
±5˚C (other than above)
±6
°F
(between 572 and 1112
°F
)
±10°F (other than above)
Sensor K(CA) thermocouple
Voltage Resolution 0.1mV
Measurement range 0 - 40 mV (AC)
Measurement tolerance
±(5% of reading +1 digit)
Resistance Resolution 0.1Ω
Measurement range 0 - 40Ω
Measurement tolerance
±(5% of reading +1 digit)
Display LCD display 3-1/2 digits
Burnout
*2
MAX HOLD function Refer to "
MAX HOLD Function" (page 7) in "4-5
Explanation about various functions".
AUTO HOLD function Refer to "
AUTO HOLD Function" (page 8) in "4-5
Explanation about various functions".
Temperature
measurement count
function
000 to 999 times
Power consumption 100V : 3.2W 100 - 110V : 3.6W
120V : 3.2W 220 - 240V : 3.6W
Outline dimensions 211(W) × 53(H) × 126(D) mm
Weight 0.95 kg
Usable temperature/humidity range 0 to 40˚C, Max. 80%RH, without condensation
Environmental conditions Applicable rated pollution degree 2
(According to IEC/UL61010-1)
*1 Temperature sensors (191-212) can only be used to measure temperatures below 500°C (932°F). To
measure higher temperatures, use an appropriate temperature probe (see
"6. REPLACEMENT PARTS/
OPTIONS").
*2 If the temperature sensor is not attached or is disconnected, "Burnout" will appear. If the temperature sensor
is disconnected, replace it with a new one. In addition, if a value out of the temperature range is detected.
"Burnout" will also appear.
NOTE
Please note that the specications and appearance are subject to change without prior notice.
