6
The lead adjuster is a tool for setting the wire
stripping length.
Adjust the distance between the blade end and
the adjuster plate to the desired wire stripping
length and slide it.
(Settable stripping length is 1 to 35mm.)
1 to 35mm
Adjuster plate
5. HOW TO USE (continued)
①
Align the wire end with the lead adjuster.
②
Pinch the wire with the blades according to
the diameter of the wire to be stripped. The
pinched area will be melted by heat.
③
Spread the heat evenly over the pinched area
by rotating the wire and the blades.
④
Pull the blades toward the wire end to be
stripped.
5-3-2 How to use the lead adjuster
5-3-3 Stripping a wire
