HAKO Scrubmaster B30 - Machine Operating Elements Overview

31
Operation
3.2.2 Operating elements on the
machine
1 Solution tank filling neck
2 Squeegee lift lever
3 Solution filter
4 Solution draining hose
5 Power supply line to charger
6 Brush head lift foot pedal
7 Waste water draining hose
8 Hand valve for water dosage 
(Scrubmaster B30 only)
Fig.11 Scrubmaster B30
2
8
1
3
4
5
6
7
