45
Maintenance and Service
5.5.1 Filling the solution tank
Fill the solution tank (Fig. 13/1) before
sta
rting work or as necessary. Park the
vehicle on a level floor area.
Open the tank cap (Fig. 13/5) and fill the
solution tank up to the maximum mark-
ing (1/1)(Fig. 13/2).
5.5.2 Emptying the solution tank
Park the machine so that the fill level
hose
(Fig. 13/3) is above a drain in the
floor. Remove the fill level hose from
the holder and remove the cover.
5.5.3 Cleaning the fresh water filter
Check the solution f
ilter (Fig. 13/4)
weekly and clean or replace it as neces-
sary.
Only clean the solution filter
when the tank is empty.
1. Empty the solution tank (Fig. 13/1),
see paragraph 5.5.2.
2. Screw the filter cap off.
3. Remove the filter element in the filter
hou
sing to clean it. Replace it with a
new one, if necessary.
4. Replace the filter e
lement and filter
cap.
